Boat Launching Rubber Air Bag , Inflatable Air Bags For Shipping
Marine rubber airbag is an innovative product of Chinese own
proprietary intellectual property rights. It has wide application
like ship launching & upgrading, caisson lifting & moving, heavy
weights lifting, underwater-engineering buoyancy aid. The marine
rubber airbag is not limited to space and heavy machinery, which
could efficiently shorten the construction period and save lots of
funds.
Marine Rubber Airbag also known as rubber airbag, ship air bags,
ship launching airbag, ship salvage airbag, boat salvage airbags,
inflatable airbag, ship lifting bag, air balloon, made by rubber &
multi layer of rubber-dipped tyre fabric.
ship launching airbag are widely used in launching and landing
ship/ boat/vessel, lifting and moving heavy goods, salvaging
stranded boats.
boat landing airbags are very popular with shipyard, ship owner,
and marine supplies company now.
Product Advantage
High Bearing Capacity
Inflatable rubber airbag’s main technical requirement is regulated
in CB/T 3795--1996 published by China State Shipbuilding
Corporation.
xincheng adopts new rubber formula and high-strength enhanced
synthetic-tyre-cord layer, which improves the airbag’s bearing
capacity two times more than CB/T 3795--1996 standard.
The synthetic-tyre-cord layer of marine airbag adopts dipped
Nylon-6 1400dtex/3-V2 tyre cord.
The strength & durability of airbag improves 20%, compared to
polyester tire cord which is widely used by friendly competitors.
Xincheng rubber is one of the earliest manufacturers of ship
airbag, our products can totally meet the ISO 14409 standard. It is
able to carry 200000 DWT ship launching, lead and innovate the
relevant safety technology of ship airbag in ship discharge and
launching. Compared with the traditional launching method, the
Marine airbag is of great environmental protection, because the
Marine airbag can assist the ship launching at any seaside, so
there is no need to worry about the construction of launching
facilities. We once produced a 35-meter long airbag for the launch
of the Indonesian customer, which broke the record of 33 meters at
that time. Our Marine airbags enjoy a high reputation all over the
world, not only in Asia but also in Africa, the Middle East,
Oceania, South America and North America.
Some normal sizes of our Marine Rubber Airbag, customized sizes are
also available
| Diameter(m) | Effective Length(m) | Layer | Pressure(MPa) |
| 1.0 | 10 | 5~6 | 0.07~0.10 |
| 1.0 | 12 | 5~6 | 0.07~0.10 |
| 1.0 | 15 | 5~6 | 0.07~0.10 |
| 1.2 | 10 | 5~6 | 0.08~0.12 |
| 1.2 | 12 | 5~6 | 0.08~0.12 |
| 1.2 | 15 | 5~6 | 0.08~0.12 |
| 1.5 | 12 | 5~8 | 0.08~0.16 |
| 1.5 | 15 | 5~8 | 0.08~0.16 |
| 1.5 | 18 | 5~8 | 0.08~0.16 |
| 1.5 | 20 | 4~8 | 0.08~0.16 |
| 1.5 | 24 | 5~8 | 0.08~0.16 |
| 1.8 | 12 | 5~8 | 0.08~0.15 |
| 1.8 | 15 | 5~8 | 0.08~0.15 |
| 1.8 | 18 | 5~8 | 0.08~0.15 |
| 1.8 | 20 | 5~8 | 0.08~0.15 |
| 1.8 | 24 | 5~8 | 0.08~0.15 |
| 2.0 | 18 | 6~10 | 0.08~0.18 |
| 2.0 | 20 | 6~10 | 0.08~0.18 |
| 2.0 | 24 | 6~10 | 0.08~0.18 |
| 2.5 | 18 | 7~10 | 0.07~0.13 |
| 2.5 | 20 | 7~10 | 0.07~0.13 |
| 2.5 | 24 | 7~10 | 0.07~0.13 |
For price quotes - please answer the following questions:
1. Type of vessel?
2. LOA (length) of ship?
3. Width of vessel?
4. Vessel's actual launched weight (gravity weight)/weight without
cargo?
5. What is the vessel's DWT?
6. Type of ground ship is built on? (Dirt, concrete, etc.)
7. Depth in meters of the water where the ship first enters the
water?
8. What's the angle degree of slipway? (Land, not under water)
9. Please provide the low/high tide schedule at site.
10. The working height? (The block stand height under the vessel)
11. Distance from bottom of propeller to the water level?
12. Distance from back of vessel (in dry dock) to the water entry
point?
